TECHNICAL SPECIFICATIONS

1. Operating temperature range: 0–70°C

2. Minimum permeate-side pressure: Pp = 0.3 bar

3. Feed tank capacity: 48L

4. Minimum circulation volume: 12L

5. pH tolerance range: 0–14

6. Filtration rate: 20–100 L/H

7. Number of membrane modules: 3 (customizable)

8. Cross-flow velocity on retentate side: Vf = 4 m/s

9. Membrane element dimensions: Length: 1016mm ± 0.2mm, Inner diameter: ф30 mm

10. Wetted parts material: SS304

11. Operating pressure: 0–0.6 MPa

12. Pump motor power: 1.5 kW

13. Power supply: Three-phase / 220V / 50Hz

14. Equipment material: SUS316L / SUS304L

15. Control mode: Manual control / Automatic control

16. Equipped with automatic overpressure protection (auto-shutdown upon overpressure) and overtemperature protection (auto-shutdown upon overtemperature)

17. Equipped with automatic backwashing system with programmable auto-backflush cycles

18. Dual membrane housing in parallel configuration; valves allow operation of either single membrane element or both elements simultaneously. Compatible with ceramic membrane elements of the following pore sizes: 50nm, 100nm, 200nm, 400nm, 600nm, 800nm, 1μm, 1.2μm, 1.5μm, 2μm, 30nm (200KD), 20nm (150KD), 12nm (100KD), 10nm (20KD), 5nm (8000D), 3nm (2000D)

19. All stainless steel welding is performed with automatic argon arc shielding protection, single-sided welding with double-sided formation. Piping features excellent internal and external surface quality, ensuring simple operation, hygienic conditions, and high safety and reliability.

20. Equipped with a heat exchanger for cooling or heating the feed material

21. Equipped with micropowder extraction and filtration function

22. Equipment dimensions: 1300 (L) × 600 (W) × 1750 (H) mm
