Technical Specifications

1. Operating temperature: 0–70°C

2. Minimum permeate side pressure: Pp = 0.3 bar

3. Feed tank capacity: 48 L

4. Minimum circulating volume: 12 L

5. pH range: 0–14

6. Filtration rate: 20–100 L/h

7. Number of membrane modules: 2 sets (customizable)

8. Crossflow velocity on circulating side: Vf = 4 m/s

9. Number of membrane modules: 3 (customizable)

10. Membrane element dimensions: 1016 mm ± 0.2 mm (length) × 30 mm (ID)

11. Filtration component material: SS304

12. Operating pressure: 0–0.6 MPa

13. Motor power: 1.5 kW

14. Power supply: Three-phase / 220V / 50Hz

15. Equipment material: SUS316L / SUS304L

16. Control mode: Manual control / Automatic control

17. Equipped with automatic overpressure protection (auto-shutdown upon overpressure) and automatic overtemperature protection (auto-shutdown upon overtemperature)

18. Equipped with an automatic backwashing system with programmable auto-backflush cycles

19. Dual membrane housing parallel configuration – through valve switching, either one membrane element or two elements can be used simultaneously. Interchangeable with ceramic membrane elements of the following pore sizes: 50 nm, 100 nm, 200 nm, 400 nm, 600 nm, 800 nm, 1 μm, 1.2 μm, 1.5 μm, 2 μm, 30 nm (200 KD), 20 nm (150 KD), 12 nm (100 KD), 10 nm (20 KD), 5 nm (8000 D), 3 nm (2000 D).

20. All stainless steel welding is performed using automatic argon-shielded welding with single-sided welding and double-sided formation, ensuring high-quality internal and external pipe surfaces. Simple operation, sanitary design, safe and reliable.

21. Equipped with a heat exchanger for cooling or heating of the feed material.

22. Equipped with micropowder extraction and filtration function.

23. Equipment dimensions: 1300 mm (L) × 600 mm (W) × 1750 mm (H).
