TECHNICAL SPECIFICATIONS

Minimum circulation volume: 50L
Cleaning tank: 150L
Feed tank: 1200L, with PP agitator
Operating pressure: 0–0.3 MPa
Allowable operating temperature: 0–60°C
Pump motor power: 11 kW
pH tolerance range: 0–14
Filtration rate: 1000–1500 L/H (varies with water quality); capable of processing 40–50 kg of powder per hour
Ceramic membrane elements: 24 pieces (interchangeable with other models of ceramic membrane elements)
All process-wetted piping is made of non-metallic FRPP material, featuring excellent wear resistance, acid/alkali resistance, and corrosion resistance for long-term durability, safety, and reliability
Equipment dimensions: 3200 (L) × 1500 (W) × 2800 (H) mm
