EQUIPMENT SPECIFICATIONS

1. Operating temperature range: 5–80°C

2. Minimum permeate-side pressure: Pp = 0.3 bar

3. Feed tank capacity: 18L / 38L

4. Minimum circulation volume: 5L / 8L

5. pH tolerance range: 0–14

6. Filtration rate: 20–100 L/H

7. Single-channel membrane area: 0.24 m²

8. Cross-flow velocity on retentate side: Vf = 4 m/s

9. Number of membrane modules: 3

10. Operating pressure: 0–0.4 MPa

11. Membrane element dimensions: 1016 mm (length) × ф30 mm (inner diameter)

12. Channel configuration: 19 channels, ф4 mm each, multi-channel cylindrical design

13. Power rating: 0.65 kW

14. Ceramic membrane element pore sizes available: 2nm, 5nm, 10nm, 12nm, 15nm, 20nm, 50nm, 100nm, 200nm, 500nm, 800nm, 1200nm, 1400nm

15. Overall dimensions: 800 × 400 × 1500 mm

16. Basic electrical control cabinet: 1 set

17. Equipped with micropowder extraction and filtration function

18. Equipment dimensions: 1300 (L) × 600 (W) × 1750 (H) mm

KEY FEATURES

• Easy to clean, with backwashing capability and strong regeneration performance

• Excellent resistance to microbial attack; does not react with microorganisms

• Outstanding chemical stability; resistant to acids, alkalis, and organic solvents

• High separation efficiency with a simple process; requires minimal auxiliary equipment, low energy consumption, and is easy to operate

• Employs cross-flow filtration; the high cross-flow velocity reduces foulant accumulation on the membrane surface, thereby enhancing membrane flux

APPLICATIONS

The ceramic membrane pilot/test equipment is particularly suitable for use in research institutes, universities and colleges, and manufacturing facilities. It can be widely applied in experimental studies involving extraction, clarification, and impurity removal in industries such as pharmaceuticals, bioengineering, food and beverage, chemicals, powder processing, and environmental protection. It serves as a valuable tool for researchers and production personnel, effectively addressing challenges that conventional processes and legacy equipment cannot resolve.
