Technical Specifications

Operating temperature: 0–70°C

Feed tank capacity: 48 L

pH range: 0–14

Filtration area: 0.75 m² per set

Number of membrane modules: 3 (customizable)

Filtration component material: SS304

Motor power: 1.5 kW

Equipment material: SUS316L / SUS304L

Equipped with automatic overpressure protection (auto-shutdown upon overpressure) and overtemperature protection (auto-shutdown upon overtemperature)

Dual membrane housing parallel configuration – through valve switching, either one or two membrane elements can be used simultaneously. Interchangeable ceramic membrane elements with pore sizes: 50nm, 100nm, 200nm, 400nm, 600nm, 800nm, 1μm, 1.2μm, 1.5μm, 2μm, 30nm (200KD), 20nm (150KD), 12nm (100KD), 10nm (20KD), 5nm (8000D), 3nm (2000D)

Equipped with a heat exchanger for cooling or heating the feed material

Equipment dimensions: 1300mm (L) × 600mm (W) × 1750mm (H)
